| MXZ2B20NA Outdoor Unit Performance: |
| Rated Cooling Capacity (BTU): |
20000 |
| Cooling Capacity Range (BTU): |
7,800 - 20,000 |
| Cooling Total Input (W): |
2,190 |
| Rated Heating Capacity (BTU): |
22,000 |
| Heating Capacity Range (BTU): |
8,500 - 25,500 |
| Heating Total Input (W): |
2,620 |
| MXZ2B20NA Outdoor Unit Power: |
| Power Supply: |
1-phase, 60Hz, 208 / 230V *2 |
| Voltage Indoor - Outdoor S1 - S2: |
AC 208 / 230V |
| Voltage Indoor - Outdoor S2 - S3: |
DC12-24V |
| MXZ2B20NA Outdoor Unit Specifications: |
| MCA (A): |
15 |
| MOCP (A): |
20 |
| Fan Motor (FLA): |
0.96 |
| MXZ2B20NA Outdoor Unit Specifications: |
| Compressor Type: |
DC Inverter-driven Twin Rotary |
| Compressor RLA: |
10.1 |
| Compressor LRA: |
15 |
| Airflow Cooling/Heating (CFM): |
1,485/1,640 |
| Refrigerant Control: |
Linear Expansion Valve |
| Defrost Method: |
Reverse Cycle |
| Cooling Sound Pressure (dB): |
49 |
| Heating Sound Pressure (dB): |
51 |
| External Finish Color: |
Munsell No. 3.0Y 7.8 / 1.1 |
| MXZ2B20NA Outdoor Unit Dimensions: |
| Width (Inches): |
33-1/16 |
| Depth (Inches): |
13 |
| Height (Inches): |
27-15/16 |
| Weight (lbs): |
130 |
| Number of Indoor Units: |
2 |
| MXZ2B20NA Refrigerant Specifications: |
| Refrigerant Type: |
R410A |
| Refrigerant Charge (Lbs, Oz): |
5, 15 |
| MXZ2B20NA Outdoor Unit Connections: |
| Gas Side O.D. (Inches): |
A,B: 3/8 |
| Liquid Side O.D. (Inches): |
1/4 |
| Max Height Difference (Feet): |
49 |
| Max Total Length (Feet): |
164 |
| SEZKD09NA4 Indoor Unit Performance: |
| Rated Cooling Capacity (BTU): |
9000 |
| Rated Heating Capacity (BTU): |
10,900 |
| SEZKD09NA4 Indoor Unit Power: |
| Power Supply: |
1-phase, 60Hz, 208 / 230V *2 |
| Voltage Indoor - Outdoor S1 - S2: |
AC 208 / 230V |
| Voltage Indoor - Outdoor S2 - S3: |
DC24V |
| SEZKD09NA4 Indoor Unit Specifications: |
| MCA (A): |
1.0 |
| Airflow Lo-Med-Hi (CFM): |
194-247-317 |
| External Static Pressure (In. W.G.): |
0.02-0.06-0.14-.020 |
| Sound Pressure Levels Lo-Med-Hi (dB): |
23-26-30 |
| External Finish Color: |
Galvanized-steel Sheets |
| SEZKD09NA4 Indoor Unit Dimensions: |
| Width (Inches): |
31/1/8 |
| Depth (Inches): |
27-9/16 |
| Height (Inches): |
7-7/8 |
| Weight (lbs): |
40 |
| Drain Lift Mechanism Height (Inches): |
21-11/16 |
| Field Drainpipe Size O.D. (Inches): |
1-1/4 |
| Remote Control Type (NOT included): |
Wired |
| SEZKD09NA4 Indoor Unit Connections: |
| Gas Side O.D. (Inches): |
3/8 |
| Liquid Side O.D. (Inches): |
1/4 |
| SEZKD12NA4 Indoor Unit Performance: |
| Rated Cooling Capacity (BTU): |
12000 |
| Rated Heating Capacity (BTU): |
13,600 |
| SEZKD12NA4 Indoor Unit Power: |
| Power Supply: |
1-phase, 60Hz, 208 / 230V *2 |
| Voltage Indoor - Outdoor S1 - S2: |
AC 208 / 230V |
| Voltage Indoor - Outdoor S2 - S3: |
DC24V |
| SEZKD12NA4 Indoor Unit Specifications: |
| MCA (A): |
1.0 |
| Airflow Lo-Med-Hi (CFM): |
247-317-388 |
| External Static Pressure (In. W.G.): |
0.02-0.06-0.14-.020 |
| Sound Pressure Levels Lo-Med-Hi (dB): |
23-28-33 |
| External Finish Color: |
Galvanized-steel Sheets |
| SEZKD12NA4 Indoor Unit Dimensions: |
| Width (Inches): |
39 |
| Depth (Inches): |
27-9/16 |
| Height (Inches): |
7-7/8 |
| Weight (lbs): |
46 |
| Drain Lift Mechanism Height (Inches): |
21-11/16 |
| Field Drainpipe Size O.D. (Inches): |
1-1/4 |
| Remote Control Type (NOT included): |
Wired |
| SEZKD12NA4 Indoor Unit Connections: |
| Gas Side O.D. (Inches): |
3/8 |
| Liquid Side O.D. (Inches): |
1/4 |
| Mitsubishi Warranty: |
| Compressor: |
7 Years |
| Parts: |
5 Years |
