Processing. Please wait. Brand: Klimaire Save Listing| Email Listing | Share Product Name: 9000 Btu Klimaire 22.8 SEER 230v Inverter Ductless Mini Split Heat And Cool System KSIE009H221I Item#: KSIE009H221I-KSIE009H221O Reg Price: $1,535.46 Your Price: $1,065.13 Accessories: Whats This? Complete Install Kit with 16 ft Wires And Copper Lines, If you need longer line set Please go to Optional accessories or call us $145.00 Opt Out Total Price : $1,210.13 Choose QTY: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Required Product Details Manuals Video Warranty Shipping Info Returns / Policy Ask A Question Product Details - KSIE009H221I-KSIE009H221O PRODUCT DETAILS: Klimaire Model Number - Indoor KSIE009-H221-I Klimaire Model Number - Outdoor KSIE009-H221-O Power supply V-ph-Hz 208-230 / 1 / 60 Cooling Capacity Btu/h 9000 Power Input W 640 Rated Current A 2,9 EER Btu/w 14 SEER Btu/w 22,8 Heating Capacity Btu/h 9800 Power Input W 930 Rated Current A 4,20 COP W/W 3,1 HSPF Btu/W 10,5 Minimum Circuit ampacity A 15 Maximum Fuse Size A 15 Compressor Type ROTARY Capacity Btu/h 10014 Power Input W 748 Indoor fan motor Power Input W 20(Output) Indoor air flow (Hi/Mi/Lo) cfm 265/205/141 Indoor noise level (Hi/Mi/Lo) db(A) 39/-/24.5 Indoor Unit Dimensions (W*D*H) in 31.57x7.44x11.69 Packing (W*D*H) in 34.45x11.22x14.76 Net/Gross weight lb 18.1/22.0 Outdoor fan motor Power Input W 40(Output) Outdoor air flow cfm 1060 Outdoor noise level dB(A) 55,5 Outdoor unit Dimensions (W*D*H) in 30.31x11.81x21.85 Packing (W*D*H) in 35.43x13.58x23.03 Net/Gross weight lb 63.9/69.4 Refrigerant Type g R410A/1000g Refrigerant Type / charge oz R410A/38.8 Refriferant precharge for up to ft 25 Additional charge per each ft oz 0,161 Design pressure psig 550/340 PSIG Liquid side/ Gas side in 1/4" / 3/8" Refrigerant piping Max. refrigerant pipe length ft 82 Max. difference in level ft 33 Connection wiring AWG 16*4 Stranded, unshielded Thermostat type Remote Control Opertion Temperature Indoor (cooling/heating) ºF 62~90/32~86 Outdoor(cooling/heating)-optional ºF 5~122/5~86 Application area (cooling standard) sq.ft 350-400 Klimaire DC Inverter Air Conditioners are the ultimate cooling and heating technology of the HVAC field. They are called “DC inverter” because the alternative current (AC) is converted to Direct Current (DC) then, direct current inverted back to Alternative current with desired frequency. As known, the current supplied through the wall outlet has fixed frequency which is 60 Hertz. Different frequencies supplied to the compressor will result different running speeds of the compressor. Klimaire Inverter control systems use Pulse Amplitude Modulation (PAM) that is the most advanced and energyefficient method of inverting the current. DC Inverter air conditioners bear special compressors that their speed could be changed by increasing or decreasing the frequency of the supplied power. Therefore, unlike conventional split Air Contioners/Heat Pumps which cycle between on and off repeatedly, the DC Inverter control system will monitor the room temperature and adjust the compressor speed automatically. Conventional compressors turn on and off to maintain the room temperature at desired level. This will result compressor to draw tremendous energy each time it starts up. This will also reduce the life-span of the compressor and other components that are turning on and off. Once a conventional system is running, it runs at its maximum speed, consuming the maximum amount of energy in order to produce the maximum of cooling or heating to maintain the desired temperature. The system will then cycle between on and off in an effort to maintain this temperature. When a DC Inverter compressor initially starts up, it runs with a higher speed to bring the room temperature to desired level rapidly, Once the set temperature is reached, it slows down and adjust its capacity just to counter the heat loss or heat gain of the building. By this way it will maintain a constant temperature. Your Phone Number : Enter Your Phone Number Your Email : Enter Your Email Not valid email address What is your message about : - Select One - Sales Questions General Support Technical Support Webmaster Please select your message about What Is The Status Of Your Project? : - Select One - Ready To Buy Planning/Budgeting Just Curious/Not Buying Anytime Soon Please select status of your project Type your name and message here : Verification Code : 2 + 3 Send Shop for Klimaire and browse manuals and details of KSIE009H221I-KSIE009H221O Air Conditioning Contractors Oklahoma City, OK HVAC Repair Olathe, KS Duct Cleaning Keller, TX HVAC Repair Walnut Creek, CA Air Conditioning Installation Gardena, CA Electricians Near Me West Jordan, UT Top Watch This Item Your Phone Number: Your Email: Message here: Make an offer Quantity you would like to buy: 1 2 3 4 5 6 7 8 9 10 How much would you like to pay for each unit: Type your Message: Shipping Address: URL of the website where you saw cheaper price Or better deal: Your email address: Your phone number: E-mail a friend about this item Your friend email: Your Email: Message here: Email For Price Your Phone Number: Your Email: Shipping Zip Code: How soon do you need this product?: Immidiately Within a week Within couple of months Just looking for price Message here:
Brand: Klimaire Save Listing| Email Listing | Share Product Name: 9000 Btu Klimaire 22.8 SEER 230v Inverter Ductless Mini Split Heat And Cool System KSIE009H221I Item#: KSIE009H221I-KSIE009H221O Reg Price: $1,535.46 Your Price: $1,065.13 Accessories: Whats This? Complete Install Kit with 16 ft Wires And Copper Lines, If you need longer line set Please go to Optional accessories or call us $145.00 Opt Out Total Price : $1,210.13 Choose QTY: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Required
Product Details Manuals Video Warranty Shipping Info Returns / Policy Ask A Question Product Details - KSIE009H221I-KSIE009H221O PRODUCT DETAILS: Klimaire Model Number - Indoor KSIE009-H221-I Klimaire Model Number - Outdoor KSIE009-H221-O Power supply V-ph-Hz 208-230 / 1 / 60 Cooling Capacity Btu/h 9000 Power Input W 640 Rated Current A 2,9 EER Btu/w 14 SEER Btu/w 22,8 Heating Capacity Btu/h 9800 Power Input W 930 Rated Current A 4,20 COP W/W 3,1 HSPF Btu/W 10,5 Minimum Circuit ampacity A 15 Maximum Fuse Size A 15 Compressor Type ROTARY Capacity Btu/h 10014 Power Input W 748 Indoor fan motor Power Input W 20(Output) Indoor air flow (Hi/Mi/Lo) cfm 265/205/141 Indoor noise level (Hi/Mi/Lo) db(A) 39/-/24.5 Indoor Unit Dimensions (W*D*H) in 31.57x7.44x11.69 Packing (W*D*H) in 34.45x11.22x14.76 Net/Gross weight lb 18.1/22.0 Outdoor fan motor Power Input W 40(Output) Outdoor air flow cfm 1060 Outdoor noise level dB(A) 55,5 Outdoor unit Dimensions (W*D*H) in 30.31x11.81x21.85 Packing (W*D*H) in 35.43x13.58x23.03 Net/Gross weight lb 63.9/69.4 Refrigerant Type g R410A/1000g Refrigerant Type / charge oz R410A/38.8 Refriferant precharge for up to ft 25 Additional charge per each ft oz 0,161 Design pressure psig 550/340 PSIG Liquid side/ Gas side in 1/4" / 3/8" Refrigerant piping Max. refrigerant pipe length ft 82 Max. difference in level ft 33 Connection wiring AWG 16*4 Stranded, unshielded Thermostat type Remote Control Opertion Temperature Indoor (cooling/heating) ºF 62~90/32~86 Outdoor(cooling/heating)-optional ºF 5~122/5~86 Application area (cooling standard) sq.ft 350-400 Klimaire DC Inverter Air Conditioners are the ultimate cooling and heating technology of the HVAC field. They are called “DC inverter” because the alternative current (AC) is converted to Direct Current (DC) then, direct current inverted back to Alternative current with desired frequency. As known, the current supplied through the wall outlet has fixed frequency which is 60 Hertz. Different frequencies supplied to the compressor will result different running speeds of the compressor. Klimaire Inverter control systems use Pulse Amplitude Modulation (PAM) that is the most advanced and energyefficient method of inverting the current. DC Inverter air conditioners bear special compressors that their speed could be changed by increasing or decreasing the frequency of the supplied power. Therefore, unlike conventional split Air Contioners/Heat Pumps which cycle between on and off repeatedly, the DC Inverter control system will monitor the room temperature and adjust the compressor speed automatically. Conventional compressors turn on and off to maintain the room temperature at desired level. This will result compressor to draw tremendous energy each time it starts up. This will also reduce the life-span of the compressor and other components that are turning on and off. Once a conventional system is running, it runs at its maximum speed, consuming the maximum amount of energy in order to produce the maximum of cooling or heating to maintain the desired temperature. The system will then cycle between on and off in an effort to maintain this temperature. When a DC Inverter compressor initially starts up, it runs with a higher speed to bring the room temperature to desired level rapidly, Once the set temperature is reached, it slows down and adjust its capacity just to counter the heat loss or heat gain of the building. By this way it will maintain a constant temperature. Your Phone Number : Enter Your Phone Number Your Email : Enter Your Email Not valid email address What is your message about : - Select One - Sales Questions General Support Technical Support Webmaster Please select your message about What Is The Status Of Your Project? : - Select One - Ready To Buy Planning/Budgeting Just Curious/Not Buying Anytime Soon Please select status of your project Type your name and message here : Verification Code : 2 + 3 Send Shop for Klimaire and browse manuals and details of KSIE009H221I-KSIE009H221O Air Conditioning Contractors Oklahoma City, OK HVAC Repair Olathe, KS Duct Cleaning Keller, TX HVAC Repair Walnut Creek, CA Air Conditioning Installation Gardena, CA Electricians Near Me West Jordan, UT Top
