Performance:
Indoor Unit Model No: FTXS36LVJU
Outdoor Unit Model No: RXS36LVJU
Cooling Capacity (Btu/hr): 36,000
Cooling Capacity (Min-Max): 10,200-36,000
Heating Capacity (Btu/hr): 38,000
Heating Capacity (Min-Max): 10,200-38,000
SEER: 17.9
EER: 8.37
HSPF: 8.3
Power Supply: 60Hz,208/230V,1p
Minimum Circuit Amps: 19.5
Maximum Overcurrent Protection: 20.0 A
Power Consumption - Cooling: 4300W
Power Consumption - Heating: 4200W
Operating Current - Cooling: 18.8A
Operating Current - Heating: 18.4A
Indoor Unit Details:
Moisture Removal (pt/h): 1.8
Airflow Rate (CFM Wet): 770/635/519/473
Airflow Rate (CFM Dry): 808/657/519/469
Sound Pressure - Cooling (H/M/L/SL): 49/45/40/37 dB(A)
Sound Pressure - Heating (H/M/L/SL): 49/44/38/35 dB(A)
Piping Connections:
Liquid (O.D.): Ø 3/8
Gas (O.D.): Ø 5/8
Condensate Drain (O.D.): Ø 5/8
Dimensions (HxWxD): 13-3/8" x 47 1/4" x 9 7/16"
Net Weight (lbs): 38.0
Condensing Unit Details:
Sound Pressure - Cooling (H/M/L/SL): 54/51 dB(A)
Sound Pressure - Heating (H/M/L/SL): 55/51 dB(A)
Operating Range - Cooling: 14-115°F
Operating Range - Cooling with Wind Baffle : 0-115°F
Operating Range - Heating: 5-75°F
Operating Range - Heating with Wind Baffle : 0-75°F
Max Piping Length: 98.4 ft
Max Piping Height: 65.6 ft
Dimensions (HxWxD): 38 15/16 x 37 x12 5/8"
Net Weight (lbs): 179
Description:
36000 BTU 3 Ton 17.9 SEER Ductless Mini Split Air Conditioner - Cool Only. Daikin’s FTXS SkyAir systems feature streamlined, wall-mounted indoor units paired with quietly compact outdoor units. Available in both heat pump and cooling only solutions, SkyAir is the ultimate duct-free solution for large bonus rooms, restaurants, shops, offices, data rooms and other light commercial projects up to 2,500 square feet. Integrated with an inverter “variable speed” compressor, SkyAir systems deliver the capacity required to maintain desired room conditions and reduce energy consumption with SEER levels up to 42% higher than previous models. This technology minimizes temperature fluctuations and provides continuous cooling and heating comfort with maximum energy savings.
Features
•Powerful Airflow Dual Flaps
•Horizontal Airflow
•3-D Airflow
•Intelligent Eye
•Space-saving design
•Outdoor Quiet operation
•Inverter "variable speed" compressor
•Fully optimized for R410A refrigerant, recognized as the future industry standard
•Offers world-renowned Daikin technician support and customer service
•Wide Angle Louvers
•Vertical Auto Swing (up and down)
•Comfortable Mode
•Indoor Unit Quiet Operation
•Automatic Operation
•Program Dry Function
•Auto Fan Speed
•Hot Start
•Mold Proof Air Filter
•Titanium Apatite Photocatalytic Air Purifying Function
•Wipe clean Flat Panel
•Econo Mode
•Powerful Mode
•Remote Controller with backlit display
•LCD Wireless Remote Control
•Indoor Unit On/Off Switch
•24 Hour On/Off Timer
•Weekly Timer
•Auto Restart after Power Failure
•Self Diagnosis with Digital Display
•Anticorrosion Treatment of Outdoor Heat Exchanger Fin
